Is there any solution to know if the running app is x86 or x64 ?

Hi,



> Anyway, I'll have to run the app to know if it's a 32 or 64 bit application...

Ages ago I used this code to get executable bitness using AutomatedBuildStudio - another fantastic tool by SmartBear that has been discontinued for some reason... 😞

I hope that you will be able to port it to the language that your test project is based on.

'////////////////////////////////////////////////////
'//                    VBScript                    //
'//         AutomatedQA Corp (c) 2002-2004         //
'//               ALK (c) 2003-2012                //
'////////////////////////////////////////////////////

' The following macro constant(s) must be defined:
' <none>
'
' The following macro variable(s) must be defined:
' smIsNativeBinary_vFileToAnalyse
' smGetBinaryBitness_BinaryBitness
'
' The following macro operation(s) must be defined:
' <none>
'-------------------------------------------------------------------------------

Option Explicit
'-----------------------------------------------------------------------------

' Function reads iBytesToRead bytes from the ADO stream (advancing pointer position in stream accordingly)
' and returns read bytes as a string
Function StreamReadBytesAsString(ByRef stream, ByVal iBytesToRead)
  Dim i
  Dim bBuffer ' byte array
  Dim strHex

  bBuffer = stream.Read(iBytesToRead)
  strHex = ""
  For i = 1 To iBytesToRead
    strHex = strHex & Chr(AscB(MidB(bBuffer, i, 1)))
  Next

  StreamReadBytesAsString = strHex
End Function
'-----------------------------------------------------------------------------

' Function reads iBytesToRead bytes from the ADO stream (advancing pointer position in stream accordingly)
' and returns read bytes as a number
Function StreamReadBytesAsNumber(ByRef stream, ByVal iBytesToRead)
  Dim i
  Dim bBuffer ' byte array
  Dim strHex

  bBuffer = stream.Read(iBytesToRead)
  strHex = ""
  For i = 1 To iBytesToRead
    strHex = Utilities.Format("%.2x", Array(AscB(MidB(bBuffer, i, 1)))) & strHex
  Next

  StreamReadBytesAsNumber = Eval("&H" & strHex)
End Function
'-----------------------------------------------------------------------------

'From: http://geekswithblogs.net/rupreet/archive/2005/11/02/58873.aspx
'also: http://www.microsoft.com/whdc/system/platform/firmware/pecoff.mspx (http://msdn.microsoft.com/library/windows/hardware/gg463125)
'also: http://stackoverflow.com/questions/480696/how-to-find-if-native-dll-is-compiled-as-x64-or-x86
'also: http://stackoverflow.com/questions/1817152/detect-whether-the-assembly-was-built-for-net-compact-framework/1817231#1817231
'also: http://stackoverflow.com/questions/1946322/how-do-i-find-out-if-a-net-assembly-contains-unmanaged-code
Function GetExecutableBitness(ByVal strFullFileName)
  Const cPEHeaderSize = &H14
  Const cDataDictionaryEntrySize = &H8 ' size of the Directory entry of the DataDictionary structure

  Dim Stream
  Dim strHex
  Dim iPEOffset
  Dim iImageBitness
'  Dim iPEHeaderSize

  GetExecutableBitness = "-1"

  Set Stream = CreateObject("ADODB.Stream")
  Stream.Type = 1 ' Binary (adTypeBinary)
'  Stream.Mode = 1 ' adModeRead
  Stream.Open
  Stream.LoadFromFile strFullFileName

  ' Check 'MZ' signature
  Stream.Position = &H0 ' = 0d contains MZ signature
  strHex = StreamReadBytesAsNumber(Stream, 2)
  If (strHex <> 23117) Then ' MZ = 0x4D 0x5A (23117 = 0x5A4D)
    Call Log.Error("'MZ' signature was not found in the " & strFullFileName & _
        " file. The value at offset 0x0 is " & strHex & "d (0x" & Hex(strHex) & "h). Expected: 0x5A4D")
    Exit Function
  End If

  Stream.Position = &H3C ' = 60d contains offset to PE header
  iPEOffset = StreamReadBytesAsNumber(Stream, 4)
'Log.Message "PE header (from 0x3Ch) starts at " & iPEOffset & "d (0x" & Hex(iPEOffset) & "h)"

  ' Check 'PE' signature
  Stream.Position = iPEOffset ' move to the PE header start
  strHex = StreamReadBytesAsNumber(Stream, 4)
  If (strHex <> 17744) Then ' PE = 0x50 0x45 (17744 = 0x4550)
    Call Log.Error("'PE' signature was not found in the " & strFullFileName & _
        " file. The value at offset 0x" & Hex(iPEOffset) & " is " & strHex & "d (0x" & Hex(strHex) & _
        "h). Expected: 0x4550")
    Exit Function
  End If
'  strHex = StreamReadBytesAsString(Stream, 2)
'  If ("PE" <> strHex) Then _
'    Log.Error(strFullFileName & " file does not contain the required 'PE' signature")

  ' Get image bitness (this magic immediately follows 'PE' signature)
  iImageBitness = StreamReadBytesAsNumber(Stream, 2)
  Select Case iImageBitness
    Case &H14C ' i386 (32-bit)
      GetExecutableBitness = "32"
    Case &H8664 ' AMD64 (64-bit)
      GetExecutableBitness = "64"
    Case Else
      Log.Error("Unsupported image file architecture: " & iImageBitness & "d (0x" & Hex(iImageBitness) & _
          "h). Expected: 0x14C (32-bit) or 0x8664 (64-bit)")
  End Select

  Stream.Close
  Set Stream = Nothing
End Function
'-----------------------------------------------------------------------------

Sub Main
'  Dim strUNCFile
'
'strUNCFile = "D:\Program Files\Automated QA\TestComplete 7\Bin\msxml4r.dll"
''strUNCFile = "\\192.168.0.1\c$\Program Files\Oracle\VirtualBox\VirtualBox.exe"
'Log.Message "strUNCFile = " & strUNCFile
'Call GetExecutableBitness(strUNCFile)
'
  Variables.smGetBinaryBitness_BinaryBitness = GetExecutableBitness(Variables.smGetBinaryBitness_BinaryFullName)
End Sub
'-------------------------------------------------------------------------------
